Jinko Solar – 535W Bifacial Solar Panel – JKM535M-72HL4-TV

Brand: Jinko Solar
SKU: JKM535M-72HL4-TV
Panel Wattage: 535 Watts
Number of Cells: 144 Cell (Half-Cut 72)
Cell Type: Bifacial Solar Panels
Backsheet Color: Clear
Frame Color: Silver
Frame Size: 40mm
Voltage (Vmp): 40.81 Votls
Voltage (Voc): 49.42 Volts
Current (Imp): 13.11 Amps
Current (Isc): 13.79 Amps

$168.00

($0.31/W)
or $14.77/mo for 12 mo at 9.96% APR with Affirm.
Full Pallet Discount: Order 27 units for $151.20 each (Auto-applied at checkout)
In Stock

A $150 Panel Handling Fee applies to orders of fewer than 27 panels to cover extra handling.

Ready to ship
Available for Pickup
Available in Vancouver (BC), Stratford (ON), Dartmouth (NS)
Jinko Solar - 535W Bifacial Solar Panel - JKM535M-72HL4-TV | Circuit Solar
Price Match Guarantee

Found a lower price? We’ll match it!

Proudly Canadian

Owned and Operated!

Product Overview

The Jinko Solar 535W Bifacial Solar Panel, model JKM535M-72HL4-TV, is a powerful and efficient addition to any solar energy system. Ideal for use in both residential and commercial applications, this bifacial solar panel captures sunlight from both sides, maximizing energy output even in low-light conditions. Easily integrated with inverters, microinverters, and grid-tie systems, this solar panel delivers reliable and sustainable energy performance. Whether you’re upgrading your current solar array or starting anew, the Jinko 535W solar panel is designed to meet your energy needs.

Key Features:

  • Maximum power output of 535W for high-efficiency energy generation
  • Bifacial technology that utilizes sunlight from both front and rear sides
  • Module efficiency of up to 20.45% for optimal performance
  • Durable construction with IP67-rated junction box ensuring water and dust resistance
  • High durability with a 5400 Pa snow load and 2400 Pa wind load rating
  • Certified by IEC61215, IEC61730 standards for quality and reliability
  • Compatible with all leading inverters and microinverters for seamless integration
  • Temperature coefficient of -0.35%/°C ensuring minimal power loss in high temperatures

The Jinko Solar 535W Bifacial Solar Panel, model JKM535M-72HL4-TV, is suited for diverse applications where space optimization and high energy output are paramount. Its advanced technology and robust design make it ideal for both on-grid and hybrid energy systems, maximizing your solar investment. This solar panel is an excellent choice for environmentally-conscious individuals and businesses looking to harness clean energy efficiently. Incorporate this solar panel into your system for a reliable, sustainable power solution.

Product Specifications
Panel Wattage: 535 Watts
Number of Cells: 144 Cell (Half-Cut 72)
Cell Type: Bifacial Solar Panels
Backsheet Color: Clear
Frame Color: Silver
Frame Size: 40mm
Voltage (Vmp): 40.81 Votls
Voltage (Voc): 49.42 Volts
Current (Imp): 13.11 Amps
Current (Isc): 13.79 Amps
Max Series Fuse Rating: 30 Amp
Weight: 65 lbs
Dimensions: 89.69 × 44.65 × 1.38 in
Pallet Qty: 27 Per Pallet
Container Qty: 540 Per Container
